Equipment and Processes:

Pre-Production Engineering:

• Bacon Software (JTS/JTQ/JTI) Real Time Job Tracking
• Frontline Genesis 2000 Front End Engineering Software (3 Seats)
• CAM 350 Front End Quote CAM Stations (3 Seats)
• Orbotech LP:9008 IHS Photo Plotter
• Kodak Film Processor
• Controlled Goods Secured Data Area
• Film Storage Area: Temperature and Humidity Controlled Area

Fabricating Equipment:

• Gardner-Denver 50Hp Compressor
• Gardner-Denver 100Hp Compressor
• Famco 48" Shear
• Brown & Boggs 42" Power Shear
• Spencer Turbine 25Hp Vacuum System
• Spencer Turbine 75Hp Vacuum System
• Automatic Stackers (2)
• Argus Infra-Red Solder Reflow - c/w Pre-cleaner, Dual Rinse and Dryer
• Argus Pre-clean/Fluxer for "HASL"
• Avalon Avtec 2000 Hot Air Solder Leveler (HASL)

Dry Film/Imaging (Yellow Room)

• Climate Controlled Clean Room Environment
• Mobile Stand Alone Hepa-Filters (4)
• Duo print 1400 Film Processor
• Western Magnum XRL 240 Dry Film Laminator
• Dynachem Model 300 Dry Film Laminator with Dust Removal System
• Print Process Expo-Aligner Fully Automatic Artwork Alignment System
• Olec AP 30 8000 Super 8 High Resolution 3/5/8 KW Exposing Unit
• Colight DMVL-1630 3/5/8 KW Exposing Unit
• Colight DMVL-1530 3/5 KW Exposing Unit With 4-Point Multiline Tooled Glass Pack
• Colight DMVL-930SA 3 KW Artwork Exposing Unit (2 Units)
• ORC HMW-201B 5 KW Exposing Unit
• Coates ASI 9025 Aqueous Developer
• TEKtroller AQ-85 Dry Film Developer Automatic Replenishing System
• Micrographics Ltd. Visitek V-24 Diazo Developer
• Multiline Semi-Automatic 4-Point Artwork Punch

Drilling/Scoring/Routing

• Excellon Century 2001 - 5 Spindle Controlled Depth Drill
• Excellon System 2000 - 4 Spindle Controlled Depth Drill
• Excellon Mark VI-C - 5 Spindle Drill
• Excellon Mark VI-E - 5 Spindle Drill
• Excellon Mark VI-F - 5 Spindle Drill
• AccuScore AS-150 - JE - NC Scoring Machine
• Excellon Mark VI-DR - 5 Spindle Drill/Router Controlled Depth Drill
• Excellon Mark VI-F - 5 Spindle Drill/Router
• PDA - P/C 50 Router - 2 Spindle Controlled Depth Drill
• Stack master Drill & Pin Machine
• Bridgeport Vertical Milling Machine
• Precise High Speed Chamfer Machine
• Bevel mate 035: Double Sided Beveller

Multi-Layer

• Eidschun/SIA Phoenix Cobra Bond Automatic Line
• Hepa Filter Lay Up Stations (2)
• Multiline Semi-Automatic Post Etch Layer Punch
• Multiline Manual Post Etch Layer Punch
• Lauffer - 6 Daylight Vacuum Multi-Layer Press - 26" x 30"
• Lauffer - 6 Daylight Cold Press - 26" x 30"
• T.M.P. - 3 Daylight Vacuum Multi-Layer Press - 26" x 30"
• T.M.P. - 6 Daylight Cold Press - 26" x 26

Wet Process/Plating

• IPS Semi Automatic Electroless Line
IPS 9 Cell Semi Automatic Desmear Line
IPS 17 Cell Semi Automatic Electroless Line
• 350 Gallon Copper Tanks - c/w 500 AMP Rectifier (4)
• 500 Gallon Copper Tanks - c/w 1000 AMP Rectifier (4)
• 350 Gallon Tin/Lead Tank - c/w 500 AMP Rectifier
• 350 Gallon Tin Tank - c/w 650 AMP Rectifier
• 500 Gallon Tin Tank - c/w 650 AMP Rectifier
• 25 Gallon Deep Nickel Tank - c/w 15 AMP Rectifier
• 25 Gallon Hard Gold Tank - c/w 15 AMP Rectifier
• ENIG - Electroless Nickel Immersion Gold Line (29 cells)
• Gold Reclaim System
• Immersion Silver Line
• Coates ASI 9025 24' Film Stripper C 1-24 c/w Film Separator
• Coates ASI 9025 24' Automatic Tin Stripping Machine
• IS Pumice Machine
• Chemcut 547 XL - Automatic Etcher - c/w Quad Rinse & Triple Flood
• Automatic Etchant Dispenser
• Bulk Etch System - 2 - 5000 Gallon Tanks
• Wassero 30" 601 Scrubbing Machine
• Wassero 30" 601 Deburring Machine
• Cemac Post Wash/Dry Units (3)
• Western Magnum Tape Master

Solder Mask/Ident Screening

• Circuit Automation DP-1500 2X Automatic LPI Solder Mask Machine
• Circuit Automation DP-10 Automatic LPI Solder Mask Machine
• Circuit Automation TC-150 Tunnel Oven
• Chemcut 547 - 30" XL LPI Solder Mask Developer
• TEKtroller PH-100S Solder Mask Developer Automatic Replenishment System
• SDI Automatic Dust Removal System
• Christopher C-Sun LPI Solder Mask Curing Oven
• Christopher PCB Dryer
• Berkley Ascor 2 KW Exposing Unit
• Metro Speed Silver Film Developer
• Argus 7725 Dual Ultra-Violet Exposing Unit
• Screen Print Bases (4)
• Grieves Convection Ovens (2)
• Precision Quincy Ovens (2)
• IPC Curing Oven

Quality/Lab/Test Equipment

• Fully Equipped Lab for Chemical Analysis
• Oxford Instruments CMI900 X-Ray Fluorescence Measurement System
• Metallurgical Microscope c/w Camera
• Nikon Microscope c/w Fiber Optic Light
• Mild MS 5 Stereo Microscope c/w Ring Fluorescent Illuminator
• Wild Heerbrugg 400x Microscope
• Aoyue SP2000 Solder Pot
• Quick 100-15S Lead-Free Solder Pot
• Unimet Unitron 1000x Microscope with Measurement System
• Micro Sectioning Equipment
• Twin City Beta scope
• Khan Digital Area Calculator
• Opto Scale Model 3581
• Omega Meter II Model 300 (Ionic Tester)
• UPA CO-9 Caviderm
• Calibration Testing Equipment
• Glen Brook Technologies X-Ray Machine
• Camtek Orion: 404 AOI System
• Camtek Orion: 806 Elite AOI System with Eye-Q add on
• TTI - 2400 Series Double Sided, Double Density Bare Board Electrical Tester
• TTI - Verification Station
• MicroCraft EMMA EMX6151 Flying Probe Tester
• MicroCraft Integrated Verification Station
• Associated Research 5203V 5KV Hi-Pot Tester
• Vision Engineering Mantis Elite 15x Microscope
• Polar Toneohm 950ML Short Locator
• MicroCraft MZ-70 Single-Ended and Differential Impedance Measurement System

Environmental

• Fully Automated Ion Exchange Waste Water Treatment Systems
4 Ion Exchange and Regeneration Columns
• Electro Winning Copper Reclaim Units (4)
• Ion Exchange General Reclaim System
• Electroless "Copper Eater"
• Automatic ph Adjustment Tank
• Silver Reclaim System
• RO Water Treatment
• DI Water Treatment
• Soft Water Treatment
